TracoPower DC-DC converters DC/DC converter (print) 615918

TracoPower Brand: TracoPower
The components referenced, manufactured by TracoPower, are compact and efficient DC/DC converters designed for varying voltage conversions and current outputs, suitable for surface mount and dual in-line package settings.
Description Image Product Buy Pricing (Ex VAT) Dim Efficiency (max.) Enclosure Height Input voltage (max.) Insulation Voltage Length Max. output current Min. input voltage Misc Attribute 1 Misc Attribute 2 Number of Outputs Operating temperature (max.) Operating temperature (min.) Output current (max.) - rounded Output current (min.) Output voltage (max.) Output voltage (min.) Output voltages Power
TracoPower TDN 1-1210WISM DC/DC Converter 12V to 3.3V 1W 300mA SMD Compact
TracoPower TDN 1-1210WISM DC/DC Converter 12V to 3.3V 1W 300mA SMD Compact
Extended range
Order code: 07-8131
MPN: TDN 1-1210WISM

Available to back orderBack-order availability date - 28/12/2025
1+ £14.90
Price per unit Ex VAT 		(L x W x H) 14.2 x 9.1 x 10.2 mm 77% SMD 10.2mm 18V DC 1600V DC 14.2mm 300mA 4.5V DC 1-1210 TDN WISM 1 90°C -40°C 300mA 0mA 3.3V DC 3.3V DC +3.3V DC 1W
TracoPower TDN 1-1212WISM DC/DC Converter 12 V 90 mA SMD Housing
TracoPower TDN 1-1212WISM DC/DC Converter 12 V 90 mA SMD Housing
Extended range
Order code: 07-8132
MPN: TDN 1-1212WISM

Available to back orderBack-order availability date - 28/12/2025
1+ £14.83
Price per unit Ex VAT 		(L x W x H) 14.2 x 9.1 x 10.2 mm 81% SMD 10.2mm 18V DC 1600V DC 14.2mm 90mA 4.5V DC TDN1-1212 WISM 1 90°C -40°C 90mA 0mA 12V DC 12V DC +12V DC 1W
TracoPower TEL 2-1210 DC/DC Converter 12V to 3.3V 500mA 2W DIL 16 Casing
TracoPower TEL 2-1210 DC/DC Converter 12V to 3.3V 500mA 2W DIL 16 Casing
Extended range
Order code: 07-8143
MPN: TEL 2-1210

Available to back orderBack-order availability date - 25/01/2026
1+ £11.05
Price per unit Ex VAT 		(L x W x H) 23.8 x 10.82 x 13.7 mm 73% DIL 16 13.7mm 18V DC 1500V DC 23.8mm 500mA 9V DC 1 75°C -40°C 500mA 3.3V DC 3.3V DC 3.3V DC 2W
TracoPower TEN 6-1215N DC/DC Converter 12V-24V 6W Single Output
TracoPower TEN 6-1215N DC/DC Converter 12V-24V 6W Single Output
Extended range
Order code: 07-8160
MPN: TEN 6-1215N

Available to back orderBack-order availability date - 28/12/2025
1+ £16.53
5+ £16.04
10+ £15.54
25+ £14.88
50+ £14.22
Price per unit Ex VAT 		(L x W x H) 31.8 x 14.3 x 20.3 mm 84% DIL 24 20.3mm 18V DC 1500V DC 31.8mm 250mA 9V DC TEN 6-1215 N 1 85°C -40°C 250mA 24V DC 24V DC 24V DC 6W
TracoPower THD 10-1212N DC/DC Converter 12V 833mA 10W Industrial-Grade
TracoPower THD 10-1212N DC/DC Converter 12V 833mA 10W Industrial-Grade
Extended range
Order code: 07-8200
MPN: THD 10-1212N

Available to back orderBack-order availability date - 28/12/2025
1+ £20.86
Price per unit Ex VAT 		(L x W x H) 31.8 x 20.3 x 14.3 mm 88% 14.3mm 18V DC 1500V DC 31.8mm 833mA 9V DC THD 10-1212 N 1 85°C -40°C 833mA 12V DC 12V DC 12V DC 10W
TracoPower THL 10-1221 DC/DC Converter 12V to 5V -5V 2 Outputs 10W
TracoPower THL 10-1221 DC/DC Converter 12V to 5V -5V 2 Outputs 10W
Extended range
Order code: 07-8207
MPN: THL 10-1221

Out of stockBack-order availability date - 28/12/2025
1+ £26.44
5+ £25.64
10+ £24.85
25+ £23.80
50+ £22.73
Price per unit Ex VAT 		(L x W x H) 25.4 x 25.4 x 20.32 mm 84% 20.32mm 18V DC 1500V DC 25.4mm 1A 9V DC 2 80°C -40°C 1A 10W
TracoPower THN 15-1211 DC/DC Converter 12V to 5V 3A 15W 1500V Isolation
TracoPower THN 15-1211 DC/DC Converter 12V to 5V 3A 15W 1500V Isolation
Extended range
Order code: 07-8218
MPN: THN 15-1211

Available to back orderBack-order availability date - 28/12/2025
1+ £32.17
Price per unit Ex VAT 		(L x W x H) 25.4 x 25.4 x 20.32 mm 88% 20.32mm 18V DC 1500V DC 25.4mm 3A 9V DC 1 85°C -40°C 3A 5V DC 5V DC 5V DC 15W
TracoPower THN 20-1211 DC/DC Converter 12V to 5V 4A 20W Ultra-Compact
TracoPower THN 20-1211 DC/DC Converter 12V to 5V 4A 20W Ultra-Compact
Extended range
Order code: 07-8220
MPN: THN 20-1211

Available to back orderBack-order availability date - 28/12/2025
1+ £38.49
5+ £37.33
10+ £36.17
25+ £34.64
50+ £33.09
Price per unit Ex VAT 		(L x W x H) 25.4 x 25.4 x 20.32 mm 90% 20.32mm 18V DC 1500V DC 25.4mm 4A 9V DC 1 75°C -40°C 4A 5V DC 5V DC 5V DC 20W
TracoPower THN 30-1212 DC/DC Converter 12V 2.5A 30W Ultra-Compact 1 Output
TracoPower THN 30-1212 DC/DC Converter 12V 2.5A 30W Ultra-Compact 1 Output
Extended range
Order code: 07-8224
MPN: THN 30-1212

Available to back orderBack-order availability date - 28/12/2025
1+ £59.38
Price per unit Ex VAT 		(L x W x H) 25.4 x 25.4 x 20.32 mm 89% 20.32mm 18V DC 1500V DC 25.4mm 2.5A 9V DC THN30-1212 1 80°C -40°C 2.5A 12V DC 12V DC 12V DC 30W
TracoPower THV 12-1500P DC/DC Converter 12V 2W Adjustable Output
TracoPower THV 12-1500P DC/DC Converter 12V 2W Adjustable Output
Extended range
Order code: 07-8226
MPN: THV 12-1500P

Available to back orderPlease contact us for lead time
1+ £299.50
Price per unit Ex VAT 		(L x W x H) 110 x 12 x 25 mm 65% 25mm 13.2V DC 110mm 1.3mA 10.8V DC 12-1500 THV P 1 60°C -10°C 1.3mA 1500V DC 0V DC 2W
TracoPower THV 12-180N DC/DC Converter 12V 12mA 2W Compact & Stable
TracoPower THV 12-180N DC/DC Converter 12V 12mA 2W Compact & Stable
Extended range
Order code: 07-8227
MPN: THV 12-180N

Available to back orderPlease contact us for lead time
1+ £165.91
Price per unit Ex VAT 		(L x W x H) 80 x 12 x 25 mm 65% 25mm 13.2V DC 80mm 12mA 10.8V DC 12-180 THV N 1 60°C -10°C 12mA -180V DC 0V DC 2W
TracoPower THV 12-500P DC/DC Converter 12V 2W 6mA Ultra-Compact Stable
TracoPower THV 12-500P DC/DC Converter 12V 2W 6mA Ultra-Compact Stable
Extended range
Order code: 07-8228
MPN: THV 12-500P

Available to back orderPlease contact us for lead time
1+ £276.26
Price per unit Ex VAT 		(L x W x H) 110 x 12 x 25 mm 65% 25mm 13.2V DC 110mm 6mA 10.8V DC 12-500 THV P 1 60°C -10°C 6mA 500V DC 0V DC 2W
TracoPower TMR 1-1215 DC/DC Converter 12V to 24V 42mA 1W 1 Output SIL-6
TracoPower TMR 1-1215 DC/DC Converter 12V to 24V 42mA 1W 1 Output SIL-6
Extended range
Order code: 07-8290
MPN: TMR 1-1215

Available to back orderBack-order availability date - 28/12/2025
1+ £7.90
5+ £7.67
10+ £7.43
25+ £7.11
50+ £6.80
Price per unit Ex VAT 		(L x W x H) 17 x 7.62 x 14.2 mm 77% SIL 6 14.2mm 18V DC 1500V DC 17mm 42mA 9V DC TMR1-1215 1 85°C -40°C 42mA 24V DC 24V DC 24V DC 1W
TracoPower TMV 1215SHI DC/DC Converter 12VDC/15VDC 66mA 1W SIL7 Unreg Output
TracoPower TMV 1215SHI DC/DC Converter 12VDC/15VDC 66mA 1W SIL7 Unreg Output
Extended range
Order code: 07-8304
MPN: TMV 1215SHI

Available to back orderBack-order availability date - 25/01/2026
1+ £6.96
Price per unit Ex VAT 		(L x W x H) 19.5 x 13.4 x 7.1 mm 79% 7.1mm 13.2V DC 5200V DC 19.5mm 66mA 11.8V DC TMV 1215 SHI 1 85°C -40°C 66mA 15V DC 15V DC 15V DC 1W
TracoPower TMV 2-1209DHI DC/DC Converter 12V DC 2 Outputs 1W Compact SIL7
TracoPower TMV 2-1209DHI DC/DC Converter 12V DC 2 Outputs 1W Compact SIL7
Standard range
Order code: 07-8305
MPN: TMV 2-1209DHI

8 in stock, despatched same dayAdditional quantity lead time 4 weeks
1+ £10.29
5+ £9.97
10+ £9.67
25+ £9.26
50+ £8.84
Price per unit Ex VAT 		(L x W x H) 19.5 x 13.4 x 7.1 mm 83% SIL 7 7.1mm 13.2V DC 3000V DC 19.5mm 112mA 11.8V DC 2-1209 TMV DHI 2 80°C -40°C 112mA 1W
TracoPower TRA 3-1219 DC/DC Converter 12V/9V 333mA 3W 1 Output SIL Housing
TracoPower TRA 3-1219 DC/DC Converter 12V/9V 333mA 3W 1 Output SIL Housing
Extended range
Order code: 07-8367
MPN: TRA 3-1219

Available to back orderBack-order availability date - 25/01/2026
1+ £9.82
Price per unit Ex VAT 		(L x W x H) 19.5 x 13.4 x 7.6 mm 89% SIL 7.6mm 13.2V DC 1000V DC 19.5mm 333mA 10.8V DC 1 85°C -40°C 333mA 9V DC 9V DC 9V DC 3W
TracoPower TRN 1-1210 DC/DC Converter 12V to 3.3V 300mA 1W Compact SIL
TracoPower TRN 1-1210 DC/DC Converter 12V to 3.3V 300mA 1W Compact SIL
Extended range
Order code: 07-8369
MPN: TRN 1-1210

Available to back orderBack-order availability date - 28/12/2025
1+ £8.76
5+ £8.49
10+ £8.22
25+ £7.87
50+ £7.53
Price per unit Ex VAT 		(L x W x H) 7.7 x 11.9 x 15.1 mm 77% SIL 15.1mm 18V DC 1600V DC 7.7mm 300mA 9V DC 1 90°C -40°C 300mA 0mA 3.3V DC 3.3V DC +3.3V DC 1W
TracoPower TRN 3-1215 DC/DC Converter 12V-24V 125mA SIL Casing Compact
TracoPower TRN 3-1215 DC/DC Converter 12V-24V 125mA SIL Casing Compact
Extended range
Order code: 07-8374
MPN: TRN 3-1215

Available to back orderBack-order availability date - 25/01/2026
1+ £12.80
Price per unit Ex VAT 		(L x W x H) 7.7 x 11.9 x 15.1 mm 82% SIL 15.1mm 18V DC 1600V DC 7.7mm 125mA 9V DC TRN3-1215 1 85°C -40°C 125mA 0mA 24V DC 24V DC +24V DC 3W
