TracoPower THV 12-500P DC/DC Converter 12V 2W 6mA Ultra-Compact Stable

TracoPower
Order Code:

07-8228

Brand: TracoPower MPN: THV 12-500P
Qty Unit Price (Ex VAT)
1+ £276.26
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderPlease contact us for lead time

TracoPower's THV 12-500P is a DC/DC converter providing 12 V DC output at 6 mA with a power rating of 2 W. It features a single output and is packaged with content of one piece. Typical applications include use in telecommunications or industrial electronics where reliable voltage conversion is needed.
Connection Solder pins
Dim (L x W x H) 110 x 12 x 25 mm
Efficiency (max.) 65%
Height 25mm
Input voltage (max.) 13.2V DC
Length 110mm
Max. output current 6mA
Min. input voltage 10.8V DC
Misc Attribute 1 12-500 THV P
Nominal Voltage 12V DC
Number of Outputs 1
Operating temperature (max.) 60°C
Operating temperature (min.) -10°C
Output current (max.) - rounded 6mA
Output voltage (max.) 500V DC
Output voltage (min.) 0V DC
Power 2W
Type DC/DC converter (print)
Width 12mm
