TracoPower THD 10-1212N DC/DC Converter 12V 833mA 10W Industrial-Grade

TracoPower
Order Code:

07-8200

Brand: TracoPower MPN: THD 10-1212N
Qty Unit Price (Ex VAT)
1+ £20.86
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 28/12/2025

The TracoPower THD 10-1212N is a DC/DC converter providing a 12 V DC input and output, with a power rating of 10 W. It delivers a maximum current of 833 mA, featuring one output. Typical applications include use in industrial automation and telecommunications where stable voltage conversion is necessary.
Connection Solder pins
Dim (L x W x H) 31.8 x 20.3 x 14.3 mm
Efficiency (max.) 88%
Height 14.3mm
Input voltage (max.) 18V DC
Insulation Voltage 1500V DC
Length 31.8mm
Max. output current 833mA
Min. input voltage 9V DC
Misc Attribute 1 THD 10-1212 N
Nominal Voltage 12V DC
Number of Outputs 1
Operating temperature (max.) 85°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 833mA
Output voltage (max.) 12V DC
Output voltage (min.) 12V DC
Output voltages 12V DC
Power 10W
Type DC/DC converter (print)
Width 20.3mm
