TracoPower TEN 6-1215N DC/DC Converter 12V-24V 6W Single Output

TracoPower
Order Code:

07-8160

Brand: TracoPower MPN: TEN 6-1215N
Qty Unit Price (Ex VAT)
1+ £16.53
5+ £16.04
10+ £15.54
25+ £14.88
50+ £14.22
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 28/12/2025

The TracoPower TEN 6-1215N is a DC/DC converter designed for efficient power conversion from 12 V DC to 24 V DC with a 250 mA output current, and a 6 W power rating. It is ideal for applications requiring stable voltage regulation and is commonly used in industrial and telecommunications equipment. This high-performance, single-output converter ensures reliable operation in demanding environments.
Connection Solder pins
Dim (L x W x H) 31.8 x 14.3 x 20.3 mm
Efficiency (max.) 84%
Enclosure DIL 24
Height 20.3mm
Input voltage (max.) 18V DC
Insulation Voltage 1500V DC
Length 31.8mm
Max. output current 250mA
Min. input voltage 9V DC
Misc Attribute 1 TEN 6-1215 N
Nominal Voltage 12V DC
Number of Outputs 1
Operating temperature (max.) 85°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 250mA
Output voltage (max.) 24V DC
Output voltage (min.) 24V DC
Output voltages 24V DC
Power 6W
Type DC/DC converter (print)
Width 14.3mm
