TracoPower THL 10-1221 DC/DC Converter 12V to 5V -5V 2 Outputs 10W

The TracoPower DC/DC converter model THL 10-1221 provides dual outputs of 5 V DC and -5 V DC at a current of 1 A and power of 10 watts. It is ideal for applications requiring efficient conversion from 12 V DC and is commonly used in electronic devices and circuitry requiring stable voltage supply. This compact component is suitable for industrial automation and communication equipment.

Input Voltage Range	18V DC
Output Current	1A
Connection	Solder pins
Dim	(L x W x H) 25.4 x 25.4 x 20.32 mm
Efficiency (max.)	84%
Height	20.32mm
Insulation Voltage	1500V DC
Length	25.4mm
Max. output current	1A
Maximum Operating Temperature	80°C
Minimum Input Volage	9V DC
Nominal Voltage	12V DC
Number of Outputs	2
Operating temperature (min.)	-40°C
Power	10W
Type	DC/DC converter (print)
Weight	15g
Width	25.4mm
