TracoPower THN 15-1211 DC/DC Converter 12V to 5V 3A 15W 1500V Isolation

TracoPower
Order Code:

07-8218

Brand: TracoPower MPN: THN 15-1211
Qty Unit Price (Ex VAT)
1+ £32.17
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 28/12/2025

The TracoPower THN 15-1211 is a DC/DC converter that transforms 12 V DC to 5 V DC at 3 A, providing 15 W of power. Manufactured by TracoPower, it features a single output and is ideal for applications that require reliable voltage conversion. Typical uses include powering sensitive electronics and embedded systems in industrial environments.
Connection Solder pins
Dim (L x W x H) 25.4 x 25.4 x 20.32 mm
Efficiency (max.) 88%
Height 20.32mm
Input voltage (max.) 18V DC
Insulation Voltage 1500V DC
Length 25.4mm
Max. output current 3A
Min. input voltage 9V DC
Nominal Voltage 12V DC
Number of Outputs 1
Operating temperature (max.) 85°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 3A
Output voltage (max.) 5V DC
Output voltage (min.) 5V DC
Output voltages 5V DC
Power 15W
Type DC/DC converter (print)
Width 25.4mm
