Mean Well Open & DIN Power Supply Units Rail mounted PSU (DIN) 608296

Mean Well Brand: Mean Well
The components represent a selection of Mean Well HDR Series DIN rail power supply units known for their single output and efficient power delivery in a compact design suitable for mounting on DIN rails.
Description Image Product Buy Pricing (Ex VAT) Output Voltage Output Current Power Rating Dim Efficiency Input Voltage Inputs Length Input voltage (max.) Max. output current Max. temperature Min. input voltage Min. temperature MTBF PSU features Width Type Number of Outputs Connection Height
Mean Well HDR-100-12N HDR rail PSU 12V 7.5A 90W 1 output DIN mount
Mean Well HDR-100-12N HDR rail PSU 12V 7.5A 90W 1 output DIN mount
Standard range
Order code: 05-0741
MPN: HDR-100-12N

Available to back orderBack-order availability date - 03/01/2026
1+ £35.01
Price per unit Ex VAT 		12V DC 7.5A 90W (L x W x H) 54.5 x 70 x 90 mm 88% 47 - 63 Hz 54.5mm 7.5A 856500h Adjustable voltage output 70mm Rail mounted PSU (DIN) 1 Screw terminal 90mm
Mean Well HDR-100-15 HDR rail PSU 15V DC 6.13A 92W 1 output DIN mount
Mean Well HDR-100-15 HDR rail PSU 15V DC 6.13A 92W 1 output DIN mount
Standard range
Order code: 05-0742
MPN: HDR-100-15

Available to back orderBack-order availability date - 03/01/2026
1+ £27.70
Price per unit Ex VAT 		15V DC 6.13A 92W (L x W x H) 70 x 54.5 x 90 mm 85-264V AC 70mm 264V AC 6.13A +70°C 85V AC -30°C 856500h 54.5mm Rail mounted PSU (DIN) 1 Screw terminal 90mm
Mean Well HDR-100-24N HDR series rail PSU 24V DC 4.2A 100.8W DIN mount
Mean Well HDR-100-24N HDR series rail PSU 24V DC 4.2A 100.8W DIN mount
Standard range
Order code: 05-0744
MPN: HDR-100-24N

Available to back orderBack-order availability date - 03/01/2026
1+ £36.24
Price per unit Ex VAT 		24V DC 4.2A 100.8W (L x W x H) 54.5 x 70 x 90 mm 90% 47 - 63 Hz 54.5mm 4.2A 856500h Adjustable voltage output 70mm Rail mounted PSU (DIN) 1 Screw terminal 90mm
Mean Well HDR-100-48 HDR Rail PSU 48V DC 1.92A 92.2W DIN-rail mount
Mean Well HDR-100-48 HDR Rail PSU 48V DC 1.92A 92.2W DIN-rail mount
Standard range
Order code: 05-0745
MPN: HDR-100-48

Available to back orderBack-order availability date - 03/01/2026
1+ £28.00
Price per unit Ex VAT 		48V DC 1.92A 92.2W (L x W x H) 70 x 54.5 x 90 mm 85-264V AC 70mm 264V AC 1.92A +70°C 85V AC -30°C 856500h 54.5mm Rail mounted PSU (DIN) 1 Screw terminal 90mm
Mean Well HDR-150-12 HDR PSU 12V 135.6W; 1 output; narrow; high efficiency
Mean Well HDR-150-12 HDR PSU 12V 135.6W; 1 output; narrow; high efficiency
Standard range
Order code: 05-0746
MPN: HDR-150-12

Available to back orderBack-order availability date - 03/01/2026
1+ £44.41
Price per unit Ex VAT 		12V DC 135.6W (L x W x H) 105 x 54.5 x 90 mm 89% 1 105mm +70°C -30°C 536000h Adjustable voltage output 54.5mm Rail mounted PSU (DIN) 1 Screw terminal 90mm
Mean Well HDR-150-15 HDR PSU (DIN) 15V 142.5W 1 output compact efficient
Mean Well HDR-150-15 HDR PSU (DIN) 15V 142.5W 1 output compact efficient
Standard range
Order code: 05-0747
MPN: HDR-150-15

Available to back orderBack-order availability date - 03/01/2026
1+ £32.20
Price per unit Ex VAT 		15V DC 142.5W (L x W x H) 105 x 54.5 x 90 mm 89.5% 1 105mm +70°C -30°C 536000h Adjustable voltage output 54.5mm Rail mounted PSU (DIN) 1 Screw terminal 90mm
Mean Well HDR-150-24 HDR rail PSU 24V 150W DIN rail-mounted 1 output reinforced
Mean Well HDR-150-24 HDR rail PSU 24V 150W DIN rail-mounted 1 output reinforced
Standard range
Order code: 05-0748
MPN: HDR-150-24

Available to back orderBack-order availability date - 03/01/2026
1+ £44.41
Price per unit Ex VAT 		24V DC 150W (L x W x H) 105 x 54.5 x 90 mm 90.5% 1 105mm +70°C -30°C 536000h Adjustable voltage output 54.5mm Rail mounted PSU (DIN) 1 Screw terminal 90mm
Mean Well HDR-150-48 HDR-series DIN rail PSU 48V 153.6W 1 output
Mean Well HDR-150-48 HDR-series DIN rail PSU 48V 153.6W 1 output
Standard range
Order code: 05-0749
MPN: HDR-150-48

Available to back orderBack-order availability date - 03/01/2026
1+ £38.81
Price per unit Ex VAT 		48V DC 153.6W (L x W x H) 105 x 54.5 x 90 mm 90.5% 1 105mm +70°C -30°C 536000h Adjustable voltage output 54.5mm Rail mounted PSU (DIN) 1 Screw terminal 90mm
Mean Well HDR-15-15 HDR series DIN rail PSU 15V 1A 15W 1 output plastic
Mean Well HDR-15-15 HDR series DIN rail PSU 15V 1A 15W 1 output plastic
Standard range
Order code: 05-0751
MPN: HDR-15-15

Available to back orderBack-order availability date - 03/01/2026
1+ £15.37
Price per unit Ex VAT 		15V DC 1A 15W (L x W x H) 17.5 x 54.5 x 90 mm 85-264V AC 17.5mm 264V AC 1A +70°C 85V AC -30°C 1166000h 54.5mm Rail mounted PSU (DIN) 1 Screw terminal 90mm
Mean Well HDR-15-48 HDR rail PSU 48V 0.32A 15.4W DIN rail mounted 1 pc
Mean Well HDR-15-48 HDR rail PSU 48V 0.32A 15.4W DIN rail mounted 1 pc
Standard range
Order code: 05-0753
MPN: HDR-15-48

Available to back orderBack-order availability date - 03/01/2026
1+ £14.86
Price per unit Ex VAT 		48V DC 320mA 15.4W (L x W x H) 17.5 x 54.5 x 90 mm 85-264V AC 17.5mm 264V AC 0.32A +70°C 85V AC -30°C 1166000h 54.5mm Rail mounted PSU (DIN) 1 Screw terminal 90mm
Mean Well HDR-30-15 HDR series rail PSU 15V DC 2A 30W 1 output 1 pc
Mean Well HDR-30-15 HDR series rail PSU 15V DC 2A 30W 1 output 1 pc
Extended range
Order code: 05-0756
MPN: HDR-30-15

150 available to back orderBack-order availability date - 10/01/2026
1+ £13.44
Price per unit Ex VAT 		15V DC 2A 30W (L x W x H) 35 x 54.5 x 90 mm 85-264V AC 35mm 264V AC 2A +70°C 85V AC -30°C 968100h 54.5mm Rail mounted PSU (DIN) 1 Screw terminal 90mm
Mean Well HDR-30-48 HDR Series DIN PSU 48V 0.75A 36W 1 Output 1 pc
Mean Well HDR-30-48 HDR Series DIN PSU 48V 0.75A 36W 1 Output 1 pc
Standard range
Order code: 05-0758
MPN: HDR-30-48

Available to back orderBack-order availability date - 03/01/2026
1+ £18.63
Price per unit Ex VAT 		48V DC 750mA 36W (L x W x H) 35 x 54.5 x 90 mm 85-264V AC 35mm 264V AC 0.75A +70°C 85V AC -30°C 968100h 54.5mm Rail mounted PSU (DIN) 1 Screw terminal 90mm
Mean Well HDR-30-5 PSU HDR series 5V 3A 1 output DIN rail mounted 15W
Mean Well HDR-30-5 PSU HDR series 5V 3A 1 output DIN rail mounted 15W
Extended range
Order code: 05-0759
MPN: HDR-30-5

188 available to back orderBack-order availability date - 10/01/2026
1+ £18.63
Price per unit Ex VAT 		5V DC 3A 15W (L x W x H) 35 x 54.5 x 90 mm 85-264V AC 35mm 264V AC 3A +70°C 85V AC -30°C 968100h 54.5mm Rail mounted PSU (DIN) 1 Screw terminal 90mm
Mean Well HDR-60-15 HDR series DIN rail PSU 15 V DC 4 A 60 W 1 Output
Mean Well HDR-60-15 HDR series DIN rail PSU 15 V DC 4 A 60 W 1 Output
Standard range
Order code: 05-0761
MPN: HDR-60-15

Available to back orderBack-order availability date - 03/01/2026
1+ £24.55
Price per unit Ex VAT 		15V DC 4A 60W (L x W x H) 52.5 x 54.5 x 90 mm 85-264V AC 52.5mm 264V AC 4A +70°C 85V AC -30°C 927600h 54.5mm Rail mounted PSU (DIN) 1 Screw terminal 90mm
Mean Well HDR-60-48 HDR series DIN rail PSU 48V DC 1.25A 60W 1 output
Mean Well HDR-60-48 HDR series DIN rail PSU 48V DC 1.25A 60W 1 output
Standard range
Order code: 05-0763
MPN: HDR-60-48

Available to back orderBack-order availability date - 03/01/2026
1+ £24.63
Price per unit Ex VAT 		48V DC 1.25A 60W (L x W x H) 52.5 x 54.5 x 90 mm 85-264V AC 52.5mm 264V AC 1.25A +70°C 85V AC -30°C 927600h 54.5mm Rail mounted PSU (DIN) 1 Screw terminal 90mm
Mean Well HDR-60-5 HDR PSU 5V 6.5A 32.5W DIN rail plastic housing
Mean Well HDR-60-5 HDR PSU 5V 6.5A 32.5W DIN rail plastic housing
Standard range
Order code: 05-0764
MPN: HDR-60-5

Available to back orderBack-order availability date - 03/01/2026
1+ £24.63
Price per unit Ex VAT 		5V DC 6.5A 32.5W (L x W x H) 52.5 x 54.5 x 90 mm 85-264V AC 52.5mm 264V AC 6.5A +70°C 85V AC -30°C 927600h 54.5mm Rail mounted PSU (DIN) 1 Screw terminal 90mm
