Mean Well HDR-150-12 HDR PSU 12V 135.6W; 1 output; narrow; high efficiency

Mean Well
Order Code:

05-0746

Brand: Mean Well MPN: HDR-150-12 EAN-13: 4021087049597
Qty Unit Price (Ex VAT)
1+ £44.41
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 13/12/2025

The Mean Well HDR-150-12 is a rail-mounted power supply unit designed for industrial applications, delivering 12 V DC and 135.6 W with a single output. It features a screw terminal connection and is ideal for use in din rail power systems. This PSU is suitable for supplying power to various industrial devices and systems requiring a stable 12 V output.
Type Rail mounted PSU (DIN)
Output Voltage 12V DC
Connection Screw terminal
Dim (L x W x H) 105 x 54.5 x 90 mm
Efficiency 89%
Height 90mm
Inputs 1
Length 105mm
Max. temperature +70°C
Min. temperature -30°C
Misc Attribute 2 Pulsed
MTBF 536000h
Number of Outputs 1
Operating temperature (max.) +70°C
Operating temperature (min.) -30°C
Output type (power supply units) Adjustable
Output voltage (max.) 13.8V DC
Output voltage (min.) 10.8V DC
Output voltage (nominal) 12V DC
Phases 1
Power 135.6W
PSU features Adjustable voltage output
Width 54.5mm
