Mean Well HDR-60-15 HDR series DIN rail PSU 15 V DC 4 A 60 W 1 Output

Mean Well
Order Code:

05-0761

Brand: Mean Well MPN: HDR-60-15 EAN-13: 4021087036573
Qty Unit Price (Ex VAT)
1+ £24.55
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 13/12/2025

The Mean Well HDR-60-15 is a rail mounted PSU (DIN) providing a 15 V DC output at 4 A, delivering up to 60 W. It is ideal for industrial applications requiring a reliable and efficient power supply module with a single output. This unit features screw terminals for secure installation and is commonly used in automation systems and control panels.
Type Rail mounted PSU (DIN)
Output Voltage 15V DC
Connection Screw terminal
Dim (L x W x H) 52.5 x 54.5 x 90 mm
Height 90mm
Input Voltage 85-264V AC
Input voltage (max.) 264V AC
Length 52.5mm
Max. output current 4A
Max. temperature +70°C
Min. input voltage 85V AC
Min. temperature -30°C
Misc Attribute 2 Pulsed
MTBF 927600h
Number of Outputs 1
Operating temperature (max.) +70°C
Operating temperature (min.) -30°C
Output current (max.) - rounded 4A
Output type (power supply units) Adjustable
Output voltage (max.) 18V DC
Output voltage (min.) 13.5V DC
Output voltage (nominal) 15V DC
Phases 1
Power 60W
Width 54.5mm
