Mean Well HDR-150-15 HDR PSU (DIN) 15V 142.5W 1 output compact efficient

Mean Well
Standard range
Order Code:

05-0747

Brand: Mean Well MPN: HDR-150-15
Qty Unit Price (Ex VAT)
1+ £31.26
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
20 in stock, despatched in 4 working days

The Mean Well HDR-150-15 is a rail mounted power supply unit designed for industrial applications, providing a 15 V DC output at 142.5 W. This single output DIN rail PSU features screw terminals, making installation straightforward. Typical applications include use in industrial control panels and automation systems, where reliable and efficient power supply is essential.
Type Rail mounted PSU (DIN)
Connection Screw terminal
Dim (L x W x H) 105 x 54.5 x 90 mm
Efficiency 89.5%
Height 90mm
Inputs 1
Length 105mm
Manufacturer part # HDR-150-15
Max. temperature +70°C
Min. temperature -30°C
Misc Attribute 1 HDR-150-15
Misc Attribute 2 Pulsed
MTBF 536000h
No. of outputs 1
Operating temperature (max.) +70°C
Operating temperature (min.) -30°C
Output type (power supply units) Adjustable
Output voltage 15V DC
Output voltage (max.) 18V DC
Output voltage (min.) 13.5V DC
Output voltage (nominal) 15V DC
Phases 1
Power 142.5W
PSU features Adjustable voltage output
Weight 310g
Width 54.5mm
