Mean Well HDR-150-48 HDR-series DIN rail PSU 48V 153.6W 1 output

Mean Well
Order Code:

05-0749

Brand: Mean Well MPN: HDR-150-48 EAN-13: 4021087049566
Qty Unit Price (Ex VAT)
1+ £38.81
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 13/12/2025

The Mean Well HDR-150-48 is a rail-mounted power supply unit designed for industrial applications. It delivers a voltage of 48 V DC with a power output of 153.6 W and connects via screw terminals. This PSU is typically used in applications requiring reliable and efficient power supply on DIN rails.
Type Rail mounted PSU (DIN)
Output Voltage 48V DC
Connection Screw terminal
Dim (L x W x H) 105 x 54.5 x 90 mm
Efficiency 90.5%
Height 90mm
Inputs 1
Length 105mm
Max. temperature +70°C
Min. temperature -30°C
Misc Attribute 2 Pulsed
MTBF 536000h
Number of Outputs 1
Operating temperature (max.) +70°C
Operating temperature (min.) -30°C
Output type (power supply units) Adjustable
Output voltage (max.) 55.2V DC
Output voltage (min.) 43.2V DC
Output voltage (nominal) 48V DC
Phases 1
Power 153.6W
PSU features Adjustable voltage output
Width 54.5mm
