Mean Well HDR-60-5 HDR PSU 5V 6.5A 32.5W DIN rail plastic housing

Mean Well
Order Code:

05-0764

Brand: Mean Well MPN: HDR-60-5 EAN-13: 4021087036542
Qty Unit Price (Ex VAT)
1+ £24.63
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 13/12/2025

The Mean Well HDR-60-5 is a rail-mounted power supply unit designed for DIN rail installations. It provides a stable output of 5 V DC with a current rating of 6.5 A and a power output of 32.5 W. This unit is ideal for industrial applications requiring reliable power distribution in compact configurations.
Type Rail mounted PSU (DIN)
Output Voltage 5V DC
Connection Screw terminal
Dim (L x W x H) 52.5 x 54.5 x 90 mm
Height 90mm
Input Voltage 85-264V AC
Input voltage (max.) 264V AC
Length 52.5mm
Max. output current 6.5A
Max. temperature +70°C
Min. input voltage 85V AC
Min. temperature -30°C
Misc Attribute 2 Pulsed
MTBF 927600h
Number of Outputs 1
Operating temperature (max.) +70°C
Operating temperature (min.) -30°C
Output current (max.) - rounded 6.5A
Output type (power supply units) Adjustable
Output voltage (max.) 5.5V DC
Output voltage (min.) 5V DC
Output voltage (nominal) 5V DC
Phases 1
Power 32.5W
Width 54.5mm
