Mean Well HDR-100-12N HDR rail PSU 12V 7.5A 90W 1 output DIN mount

Mean Well
Standard range
Order Code:

05-0741

Brand: Mean Well MPN: HDR-100-12N
Qty Unit Price (Ex VAT)
1+ £33.99
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
33 in stock, despatched in 4 working days

The Mean Well HDR-100-12N is a DIN rail-mounted power supply unit that delivers 12 V DC at 7.5 A with a total power output of 90 W. It is designed for easy installation in industrial settings and features a single output with screw terminals for secure connections. Typical applications include use in industrial automation systems, control panels, and other environments requiring reliable power delivery.
Type Rail mounted PSU (DIN)
Connection Screw terminal
Dim (L x W x H) 54.5 x 70 x 90 mm
Efficiency 88%
Height 90mm
Input Voltage 47 - 63 Hz
Length 54.5mm
Manufacturer part # HDR-100-12N
Max. output current 7.5A
Misc Attribute 1 HDR-100-12N
Misc Attribute 2 Pulsed
MTBF 856500h
No. of outputs 1
Operating temperature (max.) +70°C
Operating temperature (min.) -30°C
Output current (max.) - rounded 7.5A
Output type (power supply units) Adjustable
Output voltage 12V DC
Output voltage (max.) 13.8V DC
Output voltage (min.) 12V DC
Output voltage (nominal) 12V DC
Phases 1
Power 90W
PSU features Adjustable voltage output
Weight 270g
Width 70mm
