Mean Well HDR-15-48 HDR rail PSU 48V 0.32A 15.4W DIN rail mounted 1 pc

Mean Well
Order Code:

05-0753

Brand: Mean Well MPN: HDR-15-48 EAN-13: 4021087036658
Qty Unit Price (Ex VAT)
1+ £14.86
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 13/12/2025

The Mean Well HDR-15-48 is a rail-mounted PSU designed for industrial applications, delivering 48 V DC at 0.32 A with a power rating of 15.4 W. This DIN rail power supply unit features a screw terminal connection, ensuring secure installation. It is ideal for use in industrial control systems and other applications requiring reliable and efficient voltage regulation.
Type Rail mounted PSU (DIN)
Output Voltage 48V DC
Connection Screw terminal
Dim (L x W x H) 17.5 x 54.5 x 90 mm
Height 90mm
Input Voltage 85-264V AC
Input voltage (max.) 264V AC
Length 17.5mm
Max. output current 0.32A
Max. temperature +70°C
Min. input voltage 85V AC
Min. temperature -30°C
Misc Attribute 2 Pulsed
MTBF 1166000h
Number of Outputs 1
Operating temperature (max.) +70°C
Operating temperature (min.) -30°C
Output current (max.) - rounded 320mA
Output type (power supply units) Adjustable
Output voltage (max.) 55.2V DC
Output voltage (min.) 43.2V DC
Output voltage (nominal) 48V DC
Phases 1
Power 15.4W
Width 54.5mm
