Mean Well HDR-15-15 HDR series DIN rail PSU 15V 1A 15W 1 output plastic

Mean Well
Order Code:

05-0751

Brand: Mean Well MPN: HDR-15-15 EAN-13: 4021087036672
Qty Unit Price (Ex VAT)
1+ £15.37
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 13/12/2025

The Mean Well HDR-15-15 is a rail-mounted power supply unit with a 15 V DC output and a 1 A current rating. Featuring a compact design and screw terminal connections, it is ideal for industrial applications requiring reliable DC power delivery. With its 15 W output power and single output configuration, it is suited for powering various electronics and automation devices.
Type Rail mounted PSU (DIN)
Output Voltage 15V DC
Connection Screw terminal
Dim (L x W x H) 17.5 x 54.5 x 90 mm
Height 90mm
Input Voltage 85-264V AC
Input voltage (max.) 264V AC
Length 17.5mm
Max. output current 1A
Max. temperature +70°C
Min. input voltage 85V AC
Min. temperature -30°C
Misc Attribute 2 Pulsed
MTBF 1166000h
Number of Outputs 1
Operating temperature (max.) +70°C
Operating temperature (min.) -30°C
Output current (max.) - rounded 1A
Output type (power supply units) Adjustable
Output voltage (max.) 18V DC
Output voltage (min.) 13.5V DC
Output voltage (nominal) 15V DC
Phases 1
Power 15W
Width 54.5mm
