Helukabel Communications & Control Cables Data cable 609460

HELUKABEL Brand: HELUKABEL
The Helukabel data cables are high-quality, grey, multi-core electrical cables designed for effective data transmission.
Description Image Product Buy Pricing (Ex VAT) Bend radius (no. of ODs for fixed installation) Bend radius (no. of ODs for flexible installation) Cable type Certification marks Core layout Cross section Cross section (each core) Insulation Min. temperature range (fixed installation) Misc Attribute No. of leads Outside Ø Peak operating voltage Shielded Test voltage Twisted pair cabling (part 1) Twisted pair cabling (yes/no) Wire ID code Insulation material Factory colour
Helukabel 16003 LiYCY Data Cable 3x0.50 mm² Grey 100m
Helukabel 16003 LiYCY Data Cable 3x0.50 mm² Grey 100m
Standard range
Order code: 04-2378
MPN: 16003

5 in stock, despatched in 4 working days
1+ £73.87
Price per unit Ex VAT 		5 10 LiYCY In accordance with DIN VDE 0812, EAC Plain copper braid, DIN VDE 0295 Cl.5, finely stranded, BS 6360 cl.5, IEC 60228 cl.6 3 x 0.50 mm² 0.50mm² -40°C TRONIC-CY LiYCY 3 5.60mm 500V Yes Wire/wire 1200 V
Wire/shield 800V		 No (0) DIN 47100 without color repetition PVC Grey
Helukabel 16027 LiYCY Data Cable 3x0.75mm² Grey 100m
Helukabel 16027 LiYCY Data Cable 3x0.75mm² Grey 100m
Standard range
Order code: 04-2379
MPN: 16027

2 in stock, despatched in 4 working days
1+ £90.98
Price per unit Ex VAT 		5 10 LiYCY In accordance with DIN VDE 0812, EAC Plain copper braid, DIN VDE 0295 Cl.5, finely stranded, BS 6360 cl.5, IEC 60228 cl.26 3 x 0.75 mm² 0.75mm² -40°C TRONIC-CY (LiY-CY) 3 6.30mm 500V Yes Wire/wire 1200 V
Wire/shield 800V		 No (0) DIN 47100 without color repetition PVC Grey
Helukabel 16476 LiYCY Data Cable 3 x 1 mm² Grey 100 m
Helukabel 16476 LiYCY Data Cable 3 x 1 mm² Grey 100 m
Standard range
Order code: 04-2388
MPN: 16476

2 in stock, despatched in 4 working days
1+ £116.00
Price per unit Ex VAT 		5 10 LiYCY In accordance with DIN VDE 0812, EAC Plain copper braid, DIN VDE 0295 Cl.5, finely stranded, BS 6360 cl.5, IEC 60228 cl.13 3 x 1 mm² 1mm² -40°C TRONIC-CY LiYCY 3 6.70mm 500V Yes Wire/wire 1200 V
wire/shield 800V		 No (0) DIN 47100 without color repetition PVC Grey
Helukabel 18002 LiYY Data Cable 3x0.14mm² Grey 100m
Helukabel 18002 LiYY Data Cable 3x0.14mm² Grey 100m
Standard range
Order code: 04-2393
MPN: 18002

2 in stock, despatched in 4 working days
1+ £28.28
Price per unit Ex VAT 		4 7.5 LiYY In accordance with DIN VDE 0812, EAC Plain copper wire, 18 x 0.10 mm 3 x 0.14 mm² 0.14mm² -40°C TRONIC LiYY 3 3.70mm 350V No 1200V No (0) DIN 47100 without color repetition PVC Grey
Helukabel 18004 LiYY data Cable 5x0.14mm² grey 100m
Helukabel 18004 LiYY data Cable 5x0.14mm² grey 100m
Standard range
Order code: 04-2394
MPN: 18004

2 in stock, despatched in 4 working days
1+ £36.00
Price per unit Ex VAT 		4 7.5 LiYY In accordance with DIN VDE 0812, EAC Plain copper wire, 18 x 0.10 mm 5 x 0.14 mm² 0.14mm² -40°C TRONIC LiYY 5 4.30mm 350V No 1200V No (0) DIN 47100 without color repetition PVC Grey
Helukabel 18058 Data Cable LiYY 3x0.34 mm² Grey 100m
Helukabel 18058 Data Cable LiYY 3x0.34 mm² Grey 100m
Standard range
Order code: 04-2395
MPN: 18058

5 in stock, despatched in 4 working days
1+ £47.45
Price per unit Ex VAT 		4 7.5 LiYY In accordance with DIN VDE 0812, EAC Bare copper wire, 7x0.25 mm 3 x 0.34 mm² 0.34mm² -40°C TRONIC LiYY 3 4.40mm 500V No 2000V No (0) DIN 47100 without color repetition PVC Grey
Helukabel 18061 LiYY Data Cable 6x0.34 mm² Grey 100m
Helukabel 18061 LiYY Data Cable 6x0.34 mm² Grey 100m
Standard range
Order code: 04-2396
MPN: 18061

1 in stock, despatched in 4 working days
1+ £72.81
Price per unit Ex VAT 		4 7.5 LiYY In accordance with DIN VDE 0812, EAC Bare copper wire, 7x0.25 mm 6 x 0.34 mm² 0.34mm² -40°C TRONIC LiYY 6 5.90mm 500V No 2000V No (0) DIN 47100 without color repetition PVC Grey
Helukabel 18085 LiYY Data Cable 2x0.50mm² Grey 100m
Helukabel 18085 LiYY Data Cable 2x0.50mm² Grey 100m
Standard range
Order code: 04-2397
MPN: 18085

2 in stock, despatched in 4 working days
1+ £37.51
Price per unit Ex VAT 		4 7.5 LiYY In accordance with DIN VDE 0812, EAC Bare copper wire, Cl.5 = fine wire 2 x 0.50 mm² 0.50mm² -40°C TRONIC LiYY 2 4.60mm 500V No 2000V No (0) DIN 47100 without color repetition PVC Grey
Helukabel 18091 LiYY Data Cable 8x0.50 mm² Grey 100 m
Helukabel 18091 LiYY Data Cable 8x0.50 mm² Grey 100 m
Standard range
Order code: 04-2398
MPN: 18091

2 in stock, despatched in 4 working days
1+ £115.42
Price per unit Ex VAT 		4 7.5 LiYY In accordance with DIN VDE 0812, EAC Bare copper wire, Cl.5 = fine wire 8 x 0.50 mm² 0.50mm² -40°C TRONIC LiYY 8 7.80mm 500V No 2000V No (0) DIN 47100 without color repetition PVC Grey
Helukabel 19002 LiYY Data Cable 2x2x0.14 mm² Grey 100m
Helukabel 19002 LiYY Data Cable 2x2x0.14 mm² Grey 100m
Extended range
Order code: 04-2399
MPN: 19002

28 available to back orderBack-order availability date - 27/11/2025
1+ £36.54
Price per unit Ex VAT 		4 7.5 LiYY In accordance with DIN VDE 0812 and 0814;EAC Plain Cu 2 x 2 x 0.14 mm² 0.14mm² -30°C PAAR-TRONIC 4 4.60mm 350V No 1200 Yes (1) Yes (1) DIN 47100 PVC Grey
Helukabel 19003 Helukabel Data Cable LiYY 3x2x0.14mm² Grey 100m
Helukabel 19003 Helukabel Data Cable LiYY 3x2x0.14mm² Grey 100m
Standard range
Order code: 04-2400
MPN: 19003

1 in stock, despatched in 4 working days
1+ £66.21
Price per unit Ex VAT 		4 7.5 LiYY In accordance with DIN VDE 0812 and 0814;EAC Plain Cu 3 x 2 x 0.14 mm² 0.14mm² -30°C PAAR-TRONIC 6 5.10mm 350V No 1200 Yes (1) Yes (1) DIN 47100 PVC Grey
Helukabel 20001 LiYCY Data Cable 2x0.14mm² Grey 100m
Helukabel 20001 LiYCY Data Cable 2x0.14mm² Grey 100m
Standard range
Order code: 04-2401
MPN: 20001

4 in stock, despatched in 4 working days
1+ £41.03
Price per unit Ex VAT 		5 10 LiYCY In accordance with DIN VDE 0812, EAC Plain copper wire, 18 x 0.10 mm 2 x 0.14 mm² 0.14mm² PVC -40°C TRONIC-CY (LiY-CY) 2 3.90mm 350V Yes Wire/wire 1200 V
wire/shield 800V		 No (0) DIN 47100 without color repetition PVC Grey
Helukabel 20058 LiYCY Data Cable 4x0.34 mm² Grey 100 m
Helukabel 20058 LiYCY Data Cable 4x0.34 mm² Grey 100 m
Standard range
Order code: 04-2402
MPN: 20058

8 in stock, despatched in 4 working days
1+ £90.79
Price per unit Ex VAT 		5 10 LiYCY In accordance with DIN VDE 0812, EAC Bare copper wire, 7 x 0.25 mm 4 x 0.34 mm² 0.34mm² -40°C TRONIC-CY (LiY-CY) 4 5.50mm 500V Yes Wire/wire 1200 V
wire/shield 800V		 No (0) DIN 47100 without color repetition PVC Grey
Helukabel 21035 LiYCY Data Cable Grey 3x2x0.25mm² 50m
Helukabel 21035 LiYCY Data Cable Grey 3x2x0.25mm² 50m
Standard range
Order code: 04-2403
MPN: 21035

3 in stock, despatched in 4 working days
1+ £51.71
Price per unit Ex VAT 		10 5 LiYCY In accordance with DIN VDE 0812 and 0814;EAC CU-strand bare, Cl.5, fine-strand starting from 0,5mm². 0.14 mm² = 18 x 0.1 mm. 0.25 mm² = 14 x 0.15 mm. 0.34 mm² = 7x0.25 mm 3 x 2 x 0.25 mm² 0.25mm² -30°C PAAR-TRONIC-CY 6 6.40mm 350 V Yes Wire/wire 1200 V
wire/shield 800V		 Yes (1) Yes (1) DIN 47100 PVC Grey
