Helukabel 20058 LiYCY Data Cable 4x0.34 mm² Grey 100 m

Image Representative of Range

Helukabel 20058 LiYCY Data Cable 4x0.34 mm² Grey 100 m

HELUKABEL
Standard range
Order Code:

04-2402

Brand: HELUKABEL MPN: 20058 EAN-13: 2050005919386
Qty Unit Price (Ex VAT)
1+ £90.79
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
9 in stock, despatched in 4 working days

The Helukabel 20058 is a shielded data cable with 4 x 0.34 mm² wires, available in a 100 m grey coil. It provides effective electromagnetic compatibility, making it suitable for computer and data transmission applications. This EMC cable is ideal for environments requiring reliable signal integrity.
Type Data cable
Bend radius (no. of ODs for fixed installation) 5
Bend radius (no. of ODs for flexible installation) 10
Cable type LiYCY
Certification marks In accordance with DIN VDE 0812, EAC
Core layout Bare copper wire, 7 x 0.25 mm
Cross section 4 x 0.34 mm²
Cross section (each core) 0.34mm²
Factory colour Grey
Halogen-free No
Insulation material PVC
Manufacturer part # 20058
Max. temperature range (fixed installation) +80°C
Max. temperature range (flexible installation) +80°C
Min. temperature range (fixed installation) -40°C
Min. temperature range (flexible installation) -5°C
Misc Attribute TRONIC-CY (LiY-CY)
No. of leads 4
Outside Ø 5.50mm
Packaged Yes
Peak operating voltage 500V
Shielded Yes
Sold per metre No
Test voltage Wire/wire 1200 V
wire/shield 800V
Twisted pair cabling (part 1) No (0)
Wire ID code DIN 47100 without color repetition
