Mean Well XLG-240-L-A LED driver 239.4W adjustable outdoor surge protect

The Mean Well XLG-240-L-A LED driver delivers a constant power of 239.4 W with an adjustable current range of 350 - 1050 mA and a voltage range of 178 - 342 V DC. This driver is equipped with features such as a PFC circuit, surge protection, and overvoltage protection, making it suitable for outdoor use and flammable surfaces. Typical applications include powering LED strips and fixtures in furniture, outdoor lighting, and environments requiring reliable LED

Type	LED driver
Output Voltage	178V DC
Max Output Power	239.4W
Output Current	350mA
Colour	Metal
Connection	Open end cable
Dimensions	(L x W x H) 219 x 63 x 35.5 mm
Height	35.5mm
IP Rating	IP67
Length	219mm
Max. output current	1050mA
Max. temperature	+90°C
Min. temperature	-40°C
Misc Attribute 1	Constant power
Misc Attribute 2	Pulsed
Number of Inputs	1
Number of Outputs	1
Protection Class	I
Test mark	CE, CB, MM, ENEC, UL
Width	63mm
