Mean Well SLC03B-12 SLC 03 3W DC/DC converter 250mA 1 output 1500V DC I/O

Mean Well
Standard range
Order Code:

05-1784

Brand: Mean Well MPN: SLC03B-12
Qty Unit Price (Ex VAT)
1+ £9.52
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
1 in stock, despatched in 4 working days

The Mean Well SLC03B-12 is a DC/DC converter module that provides 250 mA and 3 W output power with a single output channel. This efficient converter is suitable for powering electronic devices requiring stable DC voltage in industrial or telecommunications applications. Its compact design allows it to be integrated easily into existing circuits requiring voltage conversion.
Type DC/DC converter (module)
Connection Pins
Dim (L x W x H) 22.1 x 13.8 x 8.55 mm
Efficiency (max.) 82%
Height 8.55mm
Input voltage (max.) 36V DC
Insulation voltage 1500V DC
Length 22.1mm
Max. output current 250mA
Min. input voltage 18V DC
Misc Attribute SLC03B-12
No. of outputs 1
Operating temperature (max.) +85°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 250mA
Output voltage (max.) 12V DC
Power 3W
PSU features DC-to-DC converter
Weight 4.5g
Width 13.8mm
