Mean Well DPAN02C-05 DPAN02 DC/DC converter 2W 2 outputs 1500V insulation

Mean Well
Standard range
Order Code:

05-0376

Brand: Mean Well MPN: DPAN02C-05
Qty Unit Price (Ex VAT)
1+ £6.75
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
2 in stock, despatched in 4 working days

The Mean Well DPAN02C-05 is a DC/DC converter module with dual outputs, capable of delivering 200 mA current and 2 W power. Designed for efficient power conversion, it is suitable for various electronic applications requiring stable direct current supply. Typical uses include powering small electronic devices and systems needing isolation between input and output.
Type DC/DC converter (module)
Connection Pins
Dim (L x W x H) 21.8 x 9.2 x 11.1 mm
Efficiency (max.) 78%
Height 11.1mm
Input voltage (max.) 75V DC
Insulation voltage 1500V DC
Length 21.8mm
Max. output current 200mA
Min. input voltage 36V DC
Misc Attribute DPAN02C-05
No. of outputs 2
Operating temperature (max.) +90°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 200mA
Power 2W
PSU features DC-to-DC converter
RoHS-compliant Yes
Weight 4.8g
Width 9.2mm
