Mean Well DETN02N-05 DC/DC converter 200 mA 2W 2 outputs module

Mean Well
Order Code:

05-0336

Brand: Mean Well MPN: DETN02N-05 EAN-13: 4021087052696
Qty Unit Price (Ex VAT)
1+ £4.65
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
5 in stock, despatched in 4 working days

The Mean Well DETN02N-05 is a DC/DC converter module with a maximum output of 2 watts and 200 mA, featuring two outputs. This device is typically used for efficient power conversion in electronic circuits, particularly where isolation is important. It is suitable for applications requiring reliable performance in compact environments.
Connection Pins
Dim (L x W x H) 15.24 x 10.9 x 7.1 mm
Efficiency (max.) 78%
Height 7.1mm
Input voltage (max.) 26.4V DC
Insulation Voltage 3000V DC
Length 15.24mm
Max. output current 200mA
Min. input voltage 21.6V DC
Number of Outputs 2
Operating temperature (max.) +100°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 200mA
Output current (min.) 20mA
Power 2W
PSU features DC-to-DC converter
Type DC/DC converter (module)
Width 10.9mm
