Mean Well DDR-480C-24 DC/DC converter 24V 20A 480W 1 output 1 pc

Mean Well
Standard range
Order Code:

05-0306

Brand: Mean Well MPN: DDR-480C-24
Qty Unit Price (Ex VAT)
1+ £163.31
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
4 in stock, despatched in 4 working days

The Mean Well DDR-480C-24 is a DC/DC converter with a single output of 24 V and 20 A, delivering 480 W of power. This device is ideal for industrial applications that require stable and efficient power conversion. It is designed to ensure reliable performance in various electronic systems where consistent power supply is critical.
Type DC/DC converter
Dim (L x W x H) 128.50 x 85.50 x 125.20 mm
Efficiency (max.) 92%
Height 125.20mm
Input voltage (max.) 67.2V DC
Insulation voltage 4.000V
Length 128.50mm
Max. output current 20A
Max. temperature +80°C
Min. input voltage 33.6V DC
Min. temperature -40°C
Misc Attribute DDR-480C-24
No. of outputs 1
Output current (max.) - rounded 20A
Output voltage (max.) 28V
Output voltage (min.) 24V
Output voltages 24V
Power 480W
PSU features Adjustable voltage output
Weight 1375g
Width 85.50mm
