Mean Well DDR-480B-24 DC/DC converter 24V 20A 480W 1 output

Mean Well
Order Code:

05-0304

Brand: Mean Well MPN: DDR-480B-24 EAN-13: 2050008469659
Qty Unit Price (Ex VAT)
1+ £175.27
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 18/12/2025

The Mean Well DDR-480B-24 is a DC/DC converter providing a single 24 V output at 20 A with a total power of 480 W. As a reliable converter suitable for industrial applications, it supports efficient power distribution in various electronic and automotive environments. This device is ideal for applications requiring stable and robust direct current conversion with high output power.
Output Voltage 24V
Input Voltage Range 33.6V DC
Output Current 20A
Number of Outputs 1
Dim (L x W x H) 128.50 x 85.50 x 125.20 mm
Efficiency (max.) 91%
Height 125.20mm
Insulation Voltage 4.000V
Length 128.50mm
Max. output current 20A
Max. temperature +80°C
Min. input voltage 16.8V DC
Min. temperature -40°C
Power 480W
PSU features Adjustable voltage output
Type DC/DC converter
Width 85.50mm
