Gaptec LC78_03-1.0 DC/DC converter 1A 1 piece rugged reliable power conversion

Gaptec LC78_03-1.0 is a robust DC-DC converter designed for efficient and reliable power conversion, making it an ideal choice for engineering applications requiring stable direct current supply. With a capacity to deliver 1 ampere of current, this component ensures dependable performance in a single compact unit, specifically engineered for rugged environments where reliability is paramount. It is employed in various applications, such as in telecommunications, industrial automation, and embedded systems, where isolation and voltage regulation are critical. The converter supports a seamless transition in systems requiring consistent power management, proving itself indispensable in configurations demanding precise power rectification and distribution.

Content	1
Dimensions	(L x W x H) 11.6 x 6.0 x 10.2 mm
Efficiency	82%
Enclosure	SIP 3
Height	10.2mm
Length	11.6mm
Max. operating temperature (derating)	85°C
Max. output current	1A
Maximum Input Volage	42V DC
Maximum Operating Temperature	85°C
Min. operating temperature (derating)	-40°C
Minimum Input Volage	4.5V DC
Operating temperature (min.)	-40°C
Output current (max.) - rounded	1A
Output voltage (max.)	3.3V DC
Product Type	DC/DC converter
Type	LC78_1.0
Weight	1.3g
Width	6.0mm
