TracoPower TSR 0.5-2450 DC/DC Converter 24V-5V 500mA SIL Housing

TracoPower
Order Code:

07-8405

Brand: TracoPower MPN: TSR 0.5-2450
Qty Unit Price (Ex VAT)
1+ £4.35
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 28/12/2025

The TracoPower TSR 0.5-2450 is a DC/DC converter providing a single 5 V DC output from a 24 V DC input with 500 mA current. It is ideal for applications requiring efficient voltage conversion and regulation in compact spaces. Common uses include electronics and telecommunications requiring precise power management.
Connection Solder pins
Dim (L x W x H) 11.5 x 14.3 x 7.55 mm
Efficiency (max.) 94%
Enclosure SIL
Height 7.55mm
Input voltage (max.) 9V DC
Length 11.5mm
Max. output current 500mA
Min. input voltage 4.5V DC
Nominal Voltage 24V DC
Number of Outputs 1
Operating temperature (max.) 90°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 500mA
Output voltage (max.) 5V DC
Output voltage (min.) 5V DC
Output voltages 5V DC
Type DC/DC converter (print)
Width 14.3mm
