Mean Well XLG-200-L-A XLG-series LED driver 200W 350-1050mA IP-rated

The Mean Well XLG-200-L-A LED driver provides a constant power of 200W with adjustable current options between 350 - 1050 mA and a voltage range of 142 - 285 V DC. It features surge protection, a power factor correction circuit, and overvoltage protection, making it suitable for outdoor use and installation on flammable surfaces. This LED driver is ideal for powering LED strips and fixtures in both indoor and outdoor lighting applications, including furniture and commercial settings.

Type	LED driver
Connection	Open end cable
Dim	(L x W x H) 199 x 63 x 35.5 mm
Factory colour	Metal
Height	35.5mm
IP Rating	IP67
Length	199mm
Max. output current	1050mA
Max. power	200W
Max. temperature	+90°C
Min. temperature	-40°C
Misc Attribute 1	Constant power
Misc Attribute 2	Pulsed
Number of Inputs	1
Number of Outputs	1
Output current (max.) - rounded	1.05A
Output current (min.)	350mA
Output voltage (max.)	285V DC
Output voltage (min.)	142V DC
Power range	200 W (max)
Protection Class	I
Test mark	CE, CB, MM, ENEC, UL
Width	63mm
