Mean Well WDR-240-48 rail PSU 48V DC 5A 240W DIN rail 1 output protected

Image Representative of Range

Mean Well WDR-240-48 rail PSU 48V DC 5A 240W DIN rail 1 output protected

Mean Well
Order Code:

05-1908

Brand: Mean Well MPN: WDR-240-48 EAN-13: 4021087017749
Qty Unit Price (Ex VAT)
1+ £110.11
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 17/12/2025

The Mean Well WDR-240-48 is a rail-mounted power supply unit offering 48 V DC output at 5 A with a total power of 240 W, featuring a single output with a screw terminal connection. This enclosed design is suitable for industrial applications and is ideal for mounting on DIN rails. It is commonly used in factory automation, control systems, and other industrial environments requiring reliable power.
Type Rail mounted PSU (DIN)
Output Voltage 48 V/DC
Connection Screw terminal
Dim (L x W x H) 63.00 x 125.20 x 113.50 mm
Height 113.50mm
Input voltage (max.) 550V AC
Length 63.00mm
Max. output current 5A
Min. input voltage 180V AC
Misc Attribute 1 Synchronised
Number of Inputs 1
Number of Outputs 1
Output current (details) 5 A
Output current (max.) - rounded 5A
Output voltage (max.) 48V DC
Output voltage (nominal) 48V DC
Power 240W
Width 125.20mm
