Mean Well SPBW03F-12 SPBW03 dc/dc converter 250mA 3W -40°C to +90°C range

Mean Well
Order Code:

05-1840

Brand: Mean Well MPN: SPBW03F-12 EAN-13: 4021087040976
Qty Unit Price (Ex VAT)
1+ £7.35
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
3 in stock, despatched in 4 working days

The Mean Well SPBW03F-12 is a DC/DC converter module capable of 3W power output with a current rating of 250 mA. It is designed to convert direct current effectively, featuring one output. Typical applications include powering electronic devices requiring stable voltage in various industrial and commercial settings.
Connection Pins
Dim (L x W x H) 21.8 x 9.2 x 11.1 mm
Efficiency (max.) 84%
Height 11.1mm
Input voltage (max.) 36V DC
Insulation Voltage 1500V DC
Length 21.8mm
Max. output current 250mA
Min. input voltage 9V DC
Number of Outputs 1
Operating temperature (max.) +85°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 250mA
Output voltage (max.) 12V DC
Power 3W
PSU features DC-to-DC converter
Type DC/DC converter (module)
Width 9.2mm
