Mean Well SPB09A-12 DC/DC converter 750mA 9W 1 output 1pc

Mean Well
Order Code:

05-1825

Brand: Mean Well MPN: SPB09A-12 EAN-13: 4021087051965
Qty Was Unit Price (Ex VAT)
1+ £14.29 £12.42
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
2 in stock, despatched in 4 working days

Mean Well's SPB09A-12 is a DC/DC converter module rated at 750 mA and 9 W with a single output. This converter is commonly used for efficient power conversion in electrical and electronic systems. Typical applications include telecommunications, industrial control, and embedded systems where stable voltage conversion is required.
Connection Pins
Dim (L x W x H) 24 x 9.6 x 11.2 mm
Efficiency (max.) 88%
Height 11.2mm
Input voltage (max.) 18V DC
Insulation Voltage 1500V DC
Length 24mm
Max. output current 750mA
Min. input voltage 9V DC
Number of Outputs 1
Operating temperature (max.) +90°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 750mA
Output voltage (max.) 12V DC
Power 9W
PSU features DC-to-DC converter
Type DC/DC converter (module)
Width 9.6mm
