Mean Well SKM10B-03 SKM 10 dc/dc converter 2.5A 10W 1 output -40 to +85°C

Name: Mean Well SKM10B-03 SKM 10 dc/dc converter 2.5A 10W 1 output -40 to +85°C
Brand: Mean Well
Price: 25.14 GBP
Availability: InStock

Standard range

Order Code:

05-1753

Brand: Mean Well MPN: SKM10B-03

RoHS Compliant
Country of Origin: China
Free UK shipping available
View Full Product Range (15)

Inc VAT

Qty	Unit Price (Ex VAT)
1+	£25.14

Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT

120 in stock, despatched in 4 working days

Product Details
Product Range
Data Sheets
Quick Quote

The Mean Well SKM10B-03 is a DC/DC converter module with a single output, rated at 2.5 A and 10 W. This module is commonly used in electronic applications that require stable voltage conversion. It is ideal for providing efficient power management in circuits.

Type	DC/DC converter (module)
Connection	Pins
Dim	(L x W x H) 25.4 x 25.4 x 10.2 mm
Efficiency (max.)	82%
Height	10.2mm
Input voltage (max.)	36V DC
Insulation voltage	1500V DC
Length	25.4mm
Max. output current	2.5A
Min. input voltage	18V DC
Misc Attribute	SKM10B-03
No. of outputs	1
Operating temperature (max.)	+85°C
Operating temperature (min.)	-40°C
Output current (max.) - rounded	2.5A
Output voltage (max.)	3.3V DC
Power	10W
PSU features	DC-to-DC converter
RoHS-compliant	Yes
Weight	18g
Width	25.4mm
