Mean Well SFTN01N-12 dc/dc converter 1W 84mA 1 output -40 to +90°C

Mean Well
Standard range
Order Code:

05-1717

Brand: Mean Well MPN: SFTN01N-12
Qty Unit Price (Ex VAT)
1+ £3.80
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
2 in stock, despatched in 4 working days

The Mean Well SFTN01N-12 is a DC/DC converter module providing a single output with a current rating of 84 mA and a power output of 1 W. It is ideal for applications requiring stable voltage conversion in electronic devices. This module is often used in distributed power architectures and local point-of-load regulation.
Type DC/DC converter (module)
Connection Pins
Dim (L x W x H) 15.24 x 10.9 x 7.1 mm
Efficiency (max.) 75%
Height 7.1mm
Input voltage (max.) 26.4V DC
Insulation voltage 3000V DC
Length 15.24mm
Max. output current 84mA
Min. input voltage 21.6V DC
Misc Attribute SFTN01N-12
No. of outputs 1
Operating temperature (max.) +90°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 84mA
Output current (min.) 8.4mA
Output voltage (max.) 12V DC
Power 1W
PSU features DC-to-DC converter
RoHS-compliant Yes
Weight 1.2g
Width 10.9mm
