Mean Well SFTN01L-12 converter 1W 1 output 84mA -40 to +90°C range

Mean Well
Order Code:

05-1711

Brand: Mean Well MPN: SFTN01L-12 EAN-13: 4021087041690
Qty Unit Price (Ex VAT)
1+ £6.17
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 12/12/2025

The Mean Well SFTN01L-12 is a DC/DC converter module with a single output, offering 1 W power and a current rating of 84 mA. This component is typically used for efficient power conversion in electronic devices requiring stable direct current. It is suitable for industrial, telecommunications, and portable power applications.
Connection Pins
Dim (L x W x H) 15.24 x 10.9 x 7.1 mm
Efficiency (max.) 80%
Height 7.1mm
Input voltage (max.) 5.5V DC
Insulation Voltage 3000V DC
Length 15.24mm
Max. output current 84mA
Min. input voltage 4.5V DC
Number of Outputs 1
Operating temperature (max.) +90°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 84mA
Output current (min.) 8.4mA
Output voltage (max.) 12V DC
Power 1W
PSU features DC-to-DC converter
Type DC/DC converter (module)
Width 10.9mm
