Mean Well SBTN01L-12 SBTN01 DC/DC converter 1W 84mA 1 output -40 to 90°C

Order Code:

05-1627

Brand: Mean Well MPN: SBTN01L-12

RoHS Compliant
Country of Origin: Taiwan

Discontinued

Product Details
Data Sheets

The Mean Well SBTN01L-12 is a DC/DC converter module that provides a single output with a current rating of 84 mA and power of 1 W. Designed for efficient power conversion, it is often used in industrial automation and telecommunications. With a compact size, it is suitable for applications that require reliable voltage regulation in constrained spaces.

Type	DC/DC converter (module)
Connection	Pins
Dim	(L x W x H) 12.9 x 10.9 x 7.1 mm
Efficiency (max.)	80%
Height	7.1mm
Input voltage (max.)	5.5V DC
Insulation voltage	1500V DC
Length	12.9mm
Max. output current	84mA
Min. input voltage	4.5V DC
Misc Attribute	SBTN01L-12
No. of outputs	1
Operating temperature (max.)	+90°C
Operating temperature (min.)	-40°C
Output current (max.) - rounded	84mA
Output current (min.)	8.4mA
Output voltage (max.)	12V DC
Power	1W
PSU features	DC-to-DC converter
RoHS-compliant	Yes
Weight	1.1g
Width	10.9mm
