Mean Well RSP-1500-15 SMPSU 16.5V 100A 1500W high-efficiency power supply

The Mean Well RSP-1500-15 is a switch mode power supply unit (SMPSU) that provides a steady 16.5 V DC output and is capable of delivering 100 A, with a total power rating of 1500 W. This unit features a robust design with screw terminals for easy installation, making it suitable for industrial applications and high-power electronics. Its reliable performance and compact size make it ideal for use in printed circuit boards or other systems requiring efficient power conversion.

Output Voltage [DC]	16.5V
Output Current	100A
Power Rating	1500W
Number of Outputs	1
Input Voltage	264V AC
Connection	Screw terminal
Dimensions	(L x W x H) 278 x 127 x 83.5 mm
Height	83.5mm
Length	278mm
Maximum Operating Temperature	+70°C
Maximum Temperature	+70°C
Min. temperature	-20°C
Minimum Input Volage	90V AC
Misc Attribute 2	closed
MTBF	265.300h
Operating temperature (min.)	-20°C
Output Voltage	13.5V DC
PFC	Yes
PSU features	Adjustable voltage output
Type	SMPSU
Weight	3.000g
Width	127mm
