Mean Well MPM-30-12 MPM series AC/DC PSU 12V 2.5A compact for medical use

Mean Well
Order Code:

05-1177

Brand: Mean Well MPN: MPM-30-12 EAN-13: 4021087042697
Qty Unit Price (Ex VAT)
1+ £15.81
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 13/12/2025

Mean Well's MPM-30-12 AC/DC power supply unit is a PCB-mounted device with a voltage output of 12 V DC and a current rating of 2.5 A. This compact and reliable PSU is ideal for applications requiring efficient power conversion on a printed circuit board. Common uses include industrial automation, telecommunications equipment, and consumer electronics.
Dim (L x W x H) 69.5 x 39 x 24 mm
Efficiency to 90%
Height 24mm
Input Frequency 47-63Hz
Input voltage (max.) 264V AC
Insulation Voltage 4000V AC
Length 69.5mm
Max. output current 2.5A
Min. input voltage 80V AC
Misc Attribute 2 Pulsed
Misc Attribute 3 1
Number of Outputs 1
Operating temperature (max.) 85°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 2.5A
Output Current 1 2.5A
Output voltage (max.) 12V DC
Output Voltage 1 12V DC
Protection Class II
Residual ripple 120 mVp-p
Tolerance (output voltage) ±2,0%
Type AC/DC PSU (print)
Width 39mm
