Mean Well MDS01L-05 DC/DC converter 200mA 1W 1 output 1pc - medical use

The Mean Well MDS01L-05 is a DC/DC converter module with a single 5V output providing 200 mA and 1 W of power. This compact converter is designed for efficient power conversion in small electronic devices. Typical applications include powering sensors, microcontrollers, or other low-power electronic components.

Output Voltage	5V DC
Input Voltage Range	5.5V DC
Power Rating	1W
Output Current	20mA
Connection	Pins
Dim	(L x W x H) 19.5 x 9.8 x 12.5 mm
Efficiency (max.)	78%
Height	12.5mm
Length	19.5mm
Max. output current	200mA
Maximum Operating Temperature	+85°C
Minimum Input Volage	4.5V DC
Number of Outputs	1
Operating temperature (min.)	-40°C
Power	1W
PSU features	DC-to-DC converter
Type	DC/DC converter (module)
Weight	4.2g
Width	9.8mm
