Mean Well ELG-75-C700B-3Y ELG series LED driver 74.9W 700mA 53-107V dimmable

Mean Well
Standard range
Order Code:

05-0521

Brand: Mean Well MPN: ELG-75-C700B-3Y
Qty Unit Price (Ex VAT)
1+ £36.68
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
2 in stock, despatched in 4 working days

The Mean Well ELG-75-C700B-3Y is an LED driver providing a constant current output of 700 mA and a power rating of 74.9 W, making it suitable for driving LED applications with a voltage range of 53 - 107 V DC. It features a 3-in-1 dimmer, surge protection, and a PFC circuit, making it versatile for both indoor and outdoor use on flammable surfaces and furniture. This driver is ideally used in
Type LED driver
Connection Open end cable
Dim (L x W x H) 180 x 63 x 35.5 mm
Factory colour Metal
Height 35.5mm
IP rating IP67
Length 180mm
Max. output current 700mA
Max. power 74.9W
Max. temperature +85°C
Min. temperature -40°C
Misc Attribute 1 Constant current
Misc Attribute 2 Pulsed
No. of inputs 1
No. of outputs 1
Output current (max.) - rounded 700mA
Output voltage (max.) 107V DC
Output voltage (min.) 53V DC
Power range 74.9 W (max)
Test mark CE, CB, MM, UL, ENEC
Weight 800g
Width 63mm
