Mean Well ELG-240-42AB-3Y LED driver 240W 39-45V DC dimmable outdoor

Mean Well
Standard range
Order Code:

05-0489

Brand: Mean Well MPN: ELG-240-42AB-3Y
Qty Unit Price (Ex VAT)
1+ £54.38
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
9 in stock, despatched in 4 working days

The Mean Well ELG-240-42AB-3Y LED driver delivers constant voltage with a power rating of 239.82 W and supports a current range of 2.86 to 5.71 A at 39 to 45 V DC. It features a 3-in-1 dimmer, surge protection, and an adjustable output, making it suitable for outdoor use on flammable surfaces and furniture. Typical applications include powering LED strips and other outdoor lighting systems, with the added
Type LED driver
Connection Open end cable
Dim (L x W x H) 244 x 71 x 37.5 mm
Factory colour Metal
Height 37.5mm
IP rating IP65
Length 244mm
Max. output current 5.71A
Max. power 239.82W
Max. temperature +90°C
Min. temperature -40°C
Misc Attribute 1 Constant voltage
Misc Attribute 2 Pulsed
No. of inputs 1
No. of outputs 1
Output current (max.) - rounded 5.71A
Output current (min.) 2.86A
Output voltage (max.) 45V DC
Output voltage (min.) 39V DC
Power range 239.82 W (max)
Protection class I
Test mark SELV, UL, MM, ENEC, CB, CE
Weight 1220g
Width 71mm
