Mean Well ELG-200-C1400B-3Y ELG series LED driver 198.9W 1400mA dimmable

Mean Well
Order Code:

05-0479

Brand: Mean Well MPN: ELG-200-C1400B-3Y EAN-13: 4021087038010
Qty Unit Price (Ex VAT)
1+ £43.39
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 12/12/2025

The Mean Well ELG-200-C1400B-3Y is an LED driver providing constant current of 198.9 W, 1400 mA, and operating between 71 - 142 V DC. It is dimmable with a 3-in-1 dimmer, suitable for flammable surfaces, and approved for use on furniture, offering protection with a PFC circuit and surge protection. This driver is ideal for both outdoor and furniture applications, ensuring safe operation across various
Type LED driver
Connection Open end cable
Dim (L x W x H) 244 x 71 x 37.5 mm
Factory colour Metal
Height 37.5mm
IP Rating IP67
Length 244mm
Max. output current 1400mA
Max. power 198.9W
Max. temperature +85°C
Min. temperature -40°C
Misc Attribute 1 Constant current
Misc Attribute 2 Pulsed
Number of Inputs 1
Number of Outputs 1
Output current (max.) - rounded 1.4A
Output voltage (max.) 142V DC
Output voltage (min.) 71V DC
Power range 198.9 W (max)
Test mark CE, CB, MM, UL, ENEC
Width 71mm
