Mean Well DPU01M-05 DPU series DC/DC converter 1W 2 outputs 100mA

Mean Well
Order Code:

05-0406

Brand: Mean Well MPN: DPU01M-05 EAN-13: 4021087046190
Qty Unit Price (Ex VAT)
2+ £3.71
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
Available to back orderBack-order availability date - 15/12/2025

The Mean Well DPU01M-05 is a DC/DC converter module that delivers 100 mA with a power output of 1 W. This compact module features dual outputs, making it ideal for applications requiring efficient power conversion in circuits with multiple voltage requirements. It is commonly used in electronic devices where space and energy efficiency are critical.
Connection Pins
Dim (L x W x H) 19.5 x 6.1 x 10.2 mm
Efficiency (max.) 81%
Height 10.2mm
Input voltage (max.) 13.2V DC
Insulation Voltage 1500V DC
Length 19.5mm
Max. output current 100mA
Min. input voltage 10.8V DC
Number of Outputs 2
Operating temperature (max.) +90°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 100mA
Power 1W
PSU features DC-to-DC converter
Type DC/DC converter (module)
Width 6.1mm
