Mean Well DKM10E-15 converter module 333 mA 10 W 2 outputs 1 pc -40°C to +85°C

Name: Mean Well DKM10E-15 converter module 333 mA 10 W 2 outputs 1 pc -40°C to +85°C
Brand: Mean Well
Price: 19.19 GBP
Availability: InStock

Standard range

Order Code:

05-0353

Brand: Mean Well MPN: DKM10E-15

RoHS Compliant
Country of Origin: China
Free UK shipping available
View Full Product Range (15)

Inc VAT

Qty	Unit Price (Ex VAT)
1+	£19.19

Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT

6 in stock, despatched in 4 working days

Product Details
Product Range
Data Sheets
Quick Quote

The Mean Well DKM10E-15 is a DC/DC converter module with a 333 mA current rating and a 10 W power output. This component features two outputs, making it suitable for applications requiring multiple voltage supplies. Typical uses include powering multiple circuit sections or devices from a single DC source.

Type	DC/DC converter (module)
Connection	Pins
Dim	(L x W x H) 25.4 x 25.4 x 10.2 mm
Efficiency (max.)	87%
Height	10.2mm
Input voltage (max.)	9V DC
Insulation voltage	1500V DC
Length	25.4mm
Max. output current	333mA
Min. input voltage	4.7V DC
Misc Attribute	DKM10E-15
No. of outputs	2
Operating temperature (max.)	+85°C
Operating temperature (min.)	-40°C
Output current (max.) - rounded	333mA
Power	10W
PSU features	DC-to-DC converter
Weight	18g
Width	25.4mm
