Mean Well DKM10A-05 DKM Series dc/dc converter 10W dual output 1A 2:1 input

Mean Well
Standard range
Order Code:

05-0341

Brand: Mean Well MPN: DKM10A-05
Qty Unit Price (Ex VAT)
1+ £22.75
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
2 in stock, despatched in 4 working days

The Mean Well DKM10A-05 is a DC/DC converter module capable of delivering up to 10 watts with a current rating of 1 ampere. It provides two outputs making it suitable for applications that require multiple power rails. This converter is ideal for industrial, telecommunications, and data communications equipment where stable DC voltage conversion is needed.
Type DC/DC converter (module)
Connection Pins
Dim (L x W x H) 25.4 x 25.4 x 10.2 mm
Efficiency (max.) 85%
Height 10.2mm
Input voltage (max.) 5.5V DC
Insulation voltage 1500V DC
Length 25.4mm
Max. output current 1A
Min. input voltage 4.5V DC
Misc Attribute DKM10A-05
No. of outputs 2
Operating temperature (max.) +85°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 1A
Power 10W
PSU features DC-to-DC converter
Weight 18g
Width 25.4mm
