Mean Well DDR-60L-15 rail mounted DC/DC converter 15V DC 4A 60W

Mean Well
Standard range
Order Code:

05-0313

Brand: Mean Well MPN: DDR-60L-15
Qty Unit Price (Ex VAT)
1+ £32.86
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
4 in stock, despatched in 4 working days

The Mean Well DDR-60L-15 is a rail-mounted DC/DC converter with a single output of 15 V DC, providing up to 4 A and 60 W of power. It is designed for industrial applications requiring reliable power conversion and can easily be mounted on a DIN rail. This power supply unit is suitable for various industrial settings where stable and efficient power delivery is essential.
Type Rail mounted DC/DC converter (DIN)
Connection Clamp
Dim (L x W x H) 52.5 x 54.5 x 90 mm
Efficiency 92%
Height 90mm
Input Voltage 18-75V DC
Input voltage (max.) 75V DC
Length 52.5mm
Manufacturer part # DDR-60L-15
Max. output current 4A
Min. input voltage 18V DC
Misc Attribute DDR-60L-15
MTBF 611000h
No. of outputs 1
Nominal input voltage 48 V/DC
Operating temperature (max.) +85°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 4A
Output type (power supply units) Adjustable
Output voltage 15V DC
Output voltage (max.) 16.5V DC
Output voltage (min.) 13.5V DC
Output voltage (nominal) 15V DC
Power 60W
Weight 216g
Width 54.5mm
