Mean Well DDR-240D-48 DIN rail DC/DC converter 48V DC 5A 240W 1 output

Mean Well
Standard range
Order Code:

05-0293

Brand: Mean Well MPN: DDR-240D-48
Qty Unit Price (Ex VAT)
1+ £101.69
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
9 in stock, despatched in 4 working days

The Mean Well DDR-240D-48 is a rail-mounted DC/DC converter designed for industrial power supply applications. It offers a 48 V DC output at 5 A and provides a total power of 240 W, suitable for powering equipment in automation and control systems. This unit is ideal for mounting on DIN rails in industrial environments where reliable and efficient power conversion is required.
Type Rail mounted DC/DC converter (DIN)
Connection Clamp
Dim (L x W x H) 40 x 113.5 x 125.2 mm
Efficiency 92.5%
Height 125.2mm
Input Voltage 67.2-154V DC
Input voltage (max.) 154V DC
Length 40mm
Manufacturer part # DDR-240D-48
Max. output current 5A
Min. input voltage 67.2V DC
Misc Attribute DDR-240D-48
MTBF 484900h
No. of outputs 1
Operating temperature (max.) +70°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 5A
Output type (power supply units) Adjustable
Output voltage 48V DC
Output voltage (max.) 54V DC
Output voltage (min.) 48V DC
Output voltage (nominal) 48V DC
Power 240W
Weight 760g
Width 113.5mm
