Mean Well DCWN06B-05 DC/DC converter 6W 500mA 2 outputs -40 to 90 °C

Mean Well
Standard range
Order Code:

05-0260

Brand: Mean Well MPN: DCWN06B-05
Qty Unit Price (Ex VAT)
1+ £9.13
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
1 in stock, despatched in 4 working days

The Mean Well DCWN06B-05 is a DC/DC converter module with two outputs, offering a current rating of 500 mA and a power output of 6 W. It is designed for applications requiring efficient current conversion and distribution, such as in telecommunications or industrial control systems. This converter is notable for its reliable performance in various electrical and electronic projects.
Type DC/DC converter (module)
Connection Pins
Dim (L x W x H) 31.8 x 20.3 x 10.2 mm
Efficiency (max.) 82%
Height 10.2mm
Input voltage (max.) 36V DC
Insulation voltage 3000V DC
Length 31.8mm
Max. output current 500mA
Min. input voltage 18V DC
Misc Attribute DCWN06B-05
No. of outputs 2
Operating temperature (max.) +90°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 500mA
Power 6W
PSU features DC-to-DC converter
Weight 12.5g
Width 20.3mm
