Helukabel 11205-100 JZ-500 Control Lead 7G 0.50 mm² Grey 100m

HELUKABEL
Standard range
Order Code:

04-2186

Brand: HELUKABEL MPN: 11205-100
Qty Unit Price (Ex VAT)
1+ £124.85
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
2 in stock, despatched in 4 working days

The Helukabel JZ-500 Control lead 7 G 0.50 mm² Grey is a flexible cable designed for optimal control and signal transmission. With seven cores and a durable grey sheath, it is ideal for industrial machinery and automation applications. This 11205-100 model by Helukabel offers robust performance over a 100 m length.
Type Control lead
Bend radius (no. of ODs for fixed installation) 4
Bend radius (no. of ODs for flexible installation) 12.5
Cable type JZ-500
Core layout Cu-strand blank, according to DIN VDE 0295 Class 5, fine-strand, BS 6360 cl.5, IEC 60228 cl.5
Cross section 7 G 0.50 mm²
Cross section (each core) 0.50mm²
Factory colour Grey
Halogen-free Yes
Insulation material Polymer
Manufacturer part # 11205-100
Max. temperature range (fixed installation) 70°C
Max. temperature range (flexible installation) 70°C
Min. temperature range (fixed installation) -40°C
Min. temperature range (flexible installation) -15°C
Misc Attribute 11205-100
No. of leads 7 G
Nominal voltage 500V
Nominal voltage U0 300V
Outside Ø 6.70mm
Packaged Yes
RoHS-compliant Yes
Sold per metre No
Test voltage 2000V
Wire ID code DIN VDE 0293
