WAGO 289-559 Interface Module 94mm (W) 50-Pin D-Female Connector

The WAGO Interface Module 94mm (W) has a sub-miniature 50-pin D-female connector for mating connectors with IDC connection and vertical plug-in direction.

The CAGE CLAMP® connection technique allows stripped solid and ferruled conductors to be pushed in. With their space saving design, the terminal block is up to 30% smaller than standard terminal block and with a conductor entry angle of less than 15° which allows easier installation in smaller spaces.

• Manufacturer type description: 289-559
• CAGE CLAMP®S Connection

Termination	Plugable/ Cage Clamp
No of Ways	50
Wire Gauge	4mm²
Category	Interface Modules and System Wiring
Height	85mm
Height inch	3.346inches
Product Main Function	Interface module
Unit Weight	KGM
Weight	123.700g
Width	94mm
Width inch	3.701inches
