TracoPower TSR 2-0525 DC/DC Converter 5V to 15V 2A No Heat Sink Needed

TracoPower
Order Code:

07-8416

Brand: TracoPower MPN: TSR 2-0525
Qty Unit Price (Ex VAT)
1+ £9.72
5+ £9.22
10+ £8.94
25+ £8.66
50+ £8.25
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 28/12/2025

The TracoPower TSR 2-0525 is a DC/DC converter that transforms a 5 V DC input to a 15 V DC output with a current of 2 A. This single-output device is typically used in applications requiring efficient voltage conversion and regulation. Ideal for compact electronic devices, the converter ensures stable power supply and is sold individually.
Connection Solder pins
Dim (L x W x H) 14 x 14.2 x 7.5 mm
Efficiency (max.) 95%
Enclosure SIL
Height 7.5mm
Input voltage (max.) 26.4V DC
Length 14mm
Max. output current 2A
Min. input voltage 21.6V DC
Nominal Voltage 5V DC
Number of Outputs 1
Operating temperature (max.) 85°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 2A
Output voltage (max.) 2.5V DC
Output voltage (min.) 2.5V DC
Output voltages 15V DC
Type DC/DC converter (print)
Width 14.2mm
