TracoPower TSR 0.5-2433SM DC/DC Converter 24V to 12V 500mA SMD Compact

TracoPower
Order Code:

07-8404

Brand: TracoPower MPN: TSR 0.5-2433SM
Qty Unit Price (Ex VAT)
1+ £6.35
5+ £6.14
10+ £5.96
25+ £5.71
50+ £5.45
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 28/12/2025

TracoPower TSR 0.5-2433SM is a direct current converter with an input of 24 V DC and an output of 12 V DC at 500 mA. It is a surface-mount device (SMD) designed for single output applications. This DC/DC converter is typically used in compact electronic devices requiring efficient voltage regulation.
Connection SMD
Dim (L x W x H) 15.3 x 13 x 9.24 mm
Efficiency (max.) 91%
Enclosure SMD
Height 9.24mm
Input voltage (max.) 5.5V DC
Length 15.3mm
Max. output current 500mA
Min. input voltage 4.5V DC
Misc Attribute 1 TSR 0.5-2433 SM
Nominal Voltage 24V DC
Number of Outputs 1
Operating temperature (max.) 85°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 500mA
Output voltage (max.) 3.3V DC
Output voltage (min.) 3.3V DC
Output voltages 12V DC
Type DC/DC converter (SMD)
Width 13mm
