TracoPower TSM 2415S Series SMD DC/DC Converter 24V-5V 1W Single Output

TracoPower
Standard range
Order Code:

07-8378

Brand: TracoPower MPN: TSM 2415S
Qty Unit Price (Ex VAT)
1+ £7.84
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
8 in stock, despatched in 4 working days

The TracoPower TSM 2415S is a DC/DC converter (SMD) designed to convert 24 V DC input to 5 V DC output at 65 mA with 1 W power. As a reliable direct current converter, it offers one output and is often utilised in circuit boards for efficient power management. Its small size and surface-mount design make it ideal for compact electronic devices requiring stable voltage conversion.
Type DC/DC converter (SMD)
Connection SMD
Dim (L x W x H) 15.24 x 7.05 x 11.1 mm
Efficiency (max.) 82%
Enclosure SMD
Height 11.1mm
Input voltage (max.) 9V DC
Insulation voltage 1000V DC
Length 15.24mm
Max. output current 65mA
Min. input voltage 4.5V DC
Misc Attribute TSM 2415S
No. of outputs 1
Nominal voltage 24V DC
Operating temperature (max.) 85°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 65mA
Output voltage (max.) 15V DC
Output voltage (min.) 15V DC
Output voltages 5V DC
Power 1W
Weight 1.2g
Width 7.05mm
